XDS4000 Series 350MHz/500MHz Digital Oscilloscope
+ Standard 400MB memory depth
+ 600,000 wfms/s refresh rate, easy to capture exceptional and low probability events
XDS4000 Series Multi-Function Touch Test Oscilloscope
Super Cost-effective 7-into-1 Integrated oscilloscope
One device, all your needs fulfilled.
Fusion of efficiency, convenience and innovation in one solution for ultimate satisfaction.
Oscilloscope
+ 350 MHz, 500 MHz; up to 5 GSa/s real-time sample rate
+ 2 or 4 analog channels
+ Standard 400 Mpts memory depth
+ Maximum waveform capture rate of 600,000 wfms/s
+ Standard 50MHz single-channel arbitrary waveform output
+ 250 MSa/s sample rate
+ 16k arbitrary waveform length
+ 64 pre-defined waveforms
+ Output amplitude 2mVpp-20Vpp
4 ½ Digits Multimeter with Data Logging Function (option)
+ Support voltage, current, capacitance, resistance, continuity, diode test
+ Built-in data logging function, can analyze the change trend of the measured object for a long time
+ 6-digit high-precision frequency counter
+ Support the statistics on the max. and min. values of the frequency
FFT Spectrum Analyzer
+ Standard FFT, real-time operation of waveform data
+ Support 4 FFT windows: Rectangular, Hamming, Hanning and Black-harris
+ Max. frequency range: oscilloscope analog bandwidth
Protocol Analysis (Option)
Support IIC, SPI, RS232/UART, CAN serial bus decoding function
Frequency Characteristic Curve
XDS4000 series can generate the sweep signal of the specified range by controlling the built-in signal generator module and output the signal to the switch power supply to carry out loop analysis test. The bode plot generated from the test can display the gain and phase variations of the system under different frequencies, enabling engineers to get a clear view about data from the bode plot. By analyzing the phase margin (PM) and gain margin (GM), they can judge whether the system is stable.
Why choose us?
In addition to the incredible 7-in-1 features, we offer irresistible reasons that will keep you coming back for more. Discover excellence beyond imagination!
Large touch screen, excellent interactive experience
10.4-inch LCD, clear waveform display, the multi-touch screen allows engineers to work more efficiently. The buttons and knobs of the traditional oscilloscope are retained to meet different operating habits.
Multimeter with data logger function, make the measurement more accurate
XDS4000 can record the data measured by the multimeter in the internal memory or external U disk, and export the CSV format for further analysis. The recording sampling interval can be set, ranging from 0.5s to 10s. Maximum duration: 3 days for internal memory and 10 days for external memory.
Product Comparison
Probe*2
Multimeter Lead(optional)
CD Rom
Power Cord
Q9 Cable
Quick Guide
Current Ext Module(optional)
USB Cable
Specifications
|
Model |
XDS4352 |
XDS4502 |
XDS4354 |
XDS4504 |
|
Bandwidth |
350MHz |
500MHz |
350MHz |
500MHz |
|
Sample Rate |
5GS/s |
|||
|
Horizontal Scale (s/div) |
500ps/div - 1000s/div, step by 1 - 2 - 5 |
|||
|
Channel |
2 |
4 |
||
|
Display |
10.4 inch LCD touch screen |
|||
|
Record length |
400M |
|||
|
Waveform Refresh Rate |
600,000 wfms/s |
|||
|
Vertical Sensitivit |
1MΩ :1mV/div~ 10V/div;50Ω : 1mV/div ~ 1V/div |
|||
|
Vertical Resolution (A/D) |
8bits |
|||
|
Input impedance |
1MΩ±2%,in parallel with 15pF±5pF;50Ω ± 2% |
|||
|
Input coupling |
DC, AC, Ground |
|||
|
Trigger type |
Edge, Video, Pulse, Slope, Runt, Windows, Timeout, Nth Edge, Logic, I2C, SPI, RS232, CAN |
|||
|
Decoding Type(optional) |
RS232, I2C, SPI, CAN |
|||
|
Automatic measurement |
Period, Frequency, Mean, PK-PK, RMS, Max, Min, Top, Base, Amplitude, Overshoot, Preshoot, Rise Time, Fall Time, +Pulse Width, -Pulse Width, +Duty Cycle, -Duty Cycle, Delay A→B, Delay A→B, Cycle RMS, Cursor RMS, Screen Duty, FRR,FRF,FFR,FFF,LRR,LRF,LFR,LFF,Phase A→B, Phase A→B, +Pulse Count, -Pulse Count, Rise Edge Count, Fall Edge Count, Area, and Cycle Area. |
|||
|
Waveform math |
＋, －, *, / ,FFT, FFTrms, Intg, Diff, Sqrt, User Defined Function, |
|||
|
Waveform storage |
100 waveforms |
|||
|
Communication interface |
USB Host, USB Device; Trig Out(Pass/Fail); LAN port; VGA port; EXT Trig In |
|||
|
Printer compatibility |
PictBridge |
|||
|
Dimension |
422 mm (W)×226 mm (H)×135 mm (D) |
|||
|
Weight |
Approx. 5 kg (without accessories) |
|||
Arb Waveform Generator Specifications
|
Max Frequency Output |
50MHz |
|
Sample Rate |
250MS/s |
|
Channel |
1 channel |
|
Vertical Resolution |
14bits |
|
Amplitude Range |
2mVpp - 5Vpp(≦50MHz); 2mVpp - 20Vpp(≦25MHz) |
|
Waveform Length |
16K |
|
Output Waveforms |
Sine, Square, Pulse, Ramp, Exponential Rise, Exponential Fall, Sin(x)/x, Step Wave, Noise,and others, total 64 built-in waveforms, and user-defined arbitrary waveform |
Multimeter Specifications (optional)
|
Full Scale Reading |
4½ digits |
Auto Range |
√ |
|
Measure |
Voltage, Current, Capacitance, Resistance, Frequency, Duty cycle, Continuity, Diode test |
||
