TAO3000 Series 2-CH Tablet Digital Storage Oscilloscope







Specific details













Many advantages











The TAO3000 series comes with a built-in 4½ digits multimeter, featuring a multimeter interface that is displayed on the same screen alongside the oscilloscope.

Additionally, the multimeter offers a data logging function, which allows for the extended recording of data over an extended period. You can then conveniently export this recorded data to a CSV file for further analysis and reference.





Low background noise allows the oscilloscope to have better small signal measurement capabilities.

High storage allows the oscilloscope to acquire longer signals.

High refresh rate allows the oscilloscope to capture waveform details and exceptional events.



Low background noise            40M record length

45000 wfms/s refresh rate, easily capturing exceptional, and low probability events









TAO3000 series handheld oscilloscopes support multiple trigger modes,

including Edge, Video, Pulse, Slope, Runt, Windows, Timeout, I2C, SPI,

RS232/UART, CAN, and Nth Edge.









Serial bus coding available in I2C, SPI,

RS232/UART, and CAN.























Support +, -, *, /, FFT, FFTrms, Intg, Diff, Sqrt, User Defined Function, digital filter (low pass, high pass, band pass, band reject).



























Built-in Wi-Fi module, the user can connect with TAO3000 through mobile device, realize the same screen display and control, store and view waveform data through app, share with friends, realize collaborative analysis, and successfully complete the work.

























Handheld Type: The back is equipped with anti-falling elastic belt.

























Bracket Type: With bracket, it can be placed on the table

























Knapsack Type: Optional outdoor Backpack



















Accessories and Packaging







Model		VDS6102		VDS6102A
bandwidth		100MHz		100MHz
channel		2CH scope + 1CH FG
Sample rate		Max 1GSa/s
Rise time		≤3.5 ns
Horizontal scale		5ns/div～100s/div，step by 1～2～5
Sampling Mode		sample, peak detect, average
Record length		10M
Input Coupling		DC, AC, ground
Input Impedance		1 MΩ ± 2%, in parallel with 15 pF ± 5 pF
Vertical Sensitivity		2mV/div～5V/div
Vertical Resolution (A/D		8bits		14bits
Max Input Voltage		40 V (DC + AC Peak)
Probe Attenuation Factor		1X，10X，100X，1000X
Channel isolation		50Hz:  100: 1，10MHz:  40: 1
Interpolation		Sin(x)/x
Vertical Range		±2 V (2 mV/div – 50 mV/div)； ±20 V (100 mV/div – 500m V/div)； ±40 V (1 V/div – 5 V/div)
LF Respond (AC, -3dB)		≥5Hz (at input, AC coupling, -3dB)
Trigger Type		edge, video, slope, pulse
Line/Field Frequency (video)		supported standards: NTSC, PAL and SECAM broadcast systems
Trigger Mode		auto, normal, single
Lissajous Figure	Bandwidth	full bandwidth
	Phase Difference	±3 degrees
Automatic Measurement		Vpp, Vmax, Vmin, Vtop, Vbase, Vamp, Vavg, Vrms, Overshoot, Preshoot, Freq, Period, Rise Time, Fall Time, Delay A→B, Delay A→B, +Width, -Width, +Duty, -Duty
Communication Interface		USB (Typ-c)；LAN, WIFi (optional)
Power Consumption		≤8W
Dimensions (W × H × D)		190mm×120mm×18mm
Device Weight		≈0.38 kg



Function Generator
Standard Waveforms	Sine (0.1 Hz - 5 MHz), Square（0.1 Hz-200 kHz), Ramp（1 Hz-10 kHz), Pulse（1 Hz-10 kHz）
Frequency Output	5 MHz
Sampling Rate	25M Sa/s
Channel	1
Vertical Resolution	10bits
Amplitude Range	10mVpp - 5Vpp
DC Offset Range (AC+DC)	±2.5V
Output Impedance	50 Ω (typical)
