XDS Series Refresh Rate and Gray Scale Digital Oscilloscope

Super Performance + 8-bit, 12-bit or 14-bit high resolution ADC, restoring the waveform detail fully + 40M record length, and 75,000 wfms/s waveform refresh rate + low background noise, vertical sensitivity in 1 mV/div - 10 V/div + multi- trigger, and bus decoding function + SCPI, and LabVIEW supported Creative New Look + ultra-thin body-design, less space accommodation + multi-interface integration - USB host, USB device, USB port for PictBridge, LAN, AUX, and more + VGA port - better solution for video expansion, and teaching demonstration + 8 inch 800 x 600 high resolution LCD + optional multi-touch screen, more user-friendly operation experience n-in-1 functions as data logger, and multimeter with data logging function, and dual-channel 25MHz / 50MHz arbitrary waveform generator, furthermore, battery pack, and WiFi module supported

Send Inquiry

Chat Now

Product Introduction

1. Leading 75,000 frame/sec waveform refresh rate, muti-level gray scale and color temperature display.

FAQ

How to understand bandwidth in oscilloscope indicators

Bandwidth is a base indicators for oscilloscope,the same as amplifier bandwidth,it is called -3dB point,which is input sine wave at oscilloscope,the frequency amplitude is reduced to 70.7% of the actual amplitude is called the bandwidth.In other words,if you measure 1V 100M sine wave and use 100M bandwidth oscilloscope,the amplitude just have 0.707V,it is for sine wave situation.so when we choose oscilloscope,in order to reach measure accuracy,that should choose maximum signal frequency is 5 times the bandwidth

Model	XDS3062A	XDS3102A	XDS3202A	XDS3102	XDS3202E	XDS3202	XDS3302
Bandwidth	60MHz	100MHz	200MHz	100MHz	200MHz		300MHz
Sample Rate	1GS/s					2GS/s	2.5GS/s
Vertical Resolution (A/D)	12 bits		14 bits	8bits
Record length	40M
Horizontal Scale (s/div)	2ns/div - 1000s/div, step by 1 - 2 - 5		1ns/div - 1000s/div, step by 1 - 2 - 5	2ns/div - 1000s/div, step by 1 - 2 - 5	1ns/div - 1000 s/div,step by 1 - 2 - 5
Channel	2 + 1 (external)
Display	8" color LCD, 800 x 600 pixels
Trigger Type	Edge, Video, Pulse, Slope, Runt, Windows, Timeout, Nth Edge, Logic, I2C, SPI, RS232,and CAN (optional)
Bus Decoding	I2C, SPI, RS232, and CAN (optional)
Communication Interface	USB host, USB device, USB port for PictBridge, Trig Out (P/F), LAN, and VGA (optional)
Power Supply	100V - 240V AC, 50/60Hz, CAT II
Power Consumption	＜15W
Fuse	2A, T class, 250V
Battery (optional)	3.7V, 13200mAh
Dimension (W x H x D)	340 x 177 x 90 mm
Weight	2.60 kg

Optional Module / Function
VGA	VGA+AV
WIF	WiFi
AWG	arb waveform generator
DMM	digital multimeter
TOU	Touch screen(capacitor-type)
