HDS-N Series 2-CH Handheld Oscilloscope
- Auto-scale Function
- 20 group automatic measurement options
- Bandwidth : 20MHz - 200MHz
- USB data transmission supported
- Multimeter newly supported SCPI
- Rechargeable Li-ion battery (6 hours' backup)
- Waveform record and replay
HDS-N Series 2-CH Handheld Oscilloscope
- 2 in 1 (DSO + Multimeter)
- Auto-scale Function
- 20 group automatic measurement options
- Bandwidth : 20MHz - 200MHz
- USB data transmission supported
- Multimeter newly supported SCPI
- Rechargeable Li-ion battery (6 hours' backup)
- Waveform record and replay
1. 2-in-1 station
Oscilloscope + 3 3/4 digits multimeter + FFT spectrum analyzer.
2. Auto-scale Function
While in auto-scale status, the oscilloscope will switch to the specific trigger mode, vertical scale and timebase scale according to the type, amplitude and frequency of input signal.
3. Trigger Sensitivity Adjustable
While in auto-scale status, the oscilloscope will switch to the specific trigger mode, vertical scale and timebase scale according to the type, amplitude and frequency of input signal.
4. Alternative trigger function
OWON HDS digital oscilloscope alternative trigger function support 2 simultaneous signal test, improve working efficiency.
About Owon
| Model | HDS1022M-I | HDS2062M-N | HDS3102M-N | HDS4202M-N | |
|---|---|---|---|---|---|
| Bandwidth | 20MHz | 60MHz | 100MHz | 200MHz | |
| Sample Rate (real time ) | 500MS/s | 1GS/s | |||
| Horizontal Scale (s/div) | 5ns/div～100s/div, step by 1～2.5～5 | 5ns/div～100s/div, step by 1～2～5 | 2ns/div～100s/div, step by 1～2～5 | ||
| Display | 3.7” color TFT display (640 × 480 pixels) | ||||
| Channel | dual | ||||
| Record Length | 6K points | ||||
| Input Coupling | DC, AC, and GND | ||||
| Vertical Sensitivity | 5mV/div～5V/div (at input) | ||||
| Vertical Resolution (A/D) | 8 bits | ||||
| Trigger Type | Edge, Video, and Alternate | ||||
| Acquisition Mode | Sample, Peak Detect, and Average | ||||
| Waveform Math | ＋, －, ×, ÷, invert, FFT | ||||
| Communication Interface | USB | ||||
| Power Supply | 100V-240V AC, 50/60Hz | ||||
| Li-ion Battery | 7.4V, 6 hours’ operation | ||||
| Dimensions (W × H × D) | 115 × 180 × 40 (mm) | ||||
| Weight (without package) | 645.00 g | ||||
| Multimeter Specifications | |||
|---|---|---|---|
| Full Scale Reading | 3(3/4) digit (max 4000-count) | diode | 0V-1V |
| Input Impedance | 10 MΩ | On / Off Test | < 50 (± 30) beeping |
| Voltage | VDC : 400mV, 4V, 40V, 400V, 1000V : ±(1% ± 1 digit); max input : DC 1000V VAC : 4V, 40V, 400V : ±(1% ± 3 digits), 750V : ±(2% ± 3 digits); Frequency : 40Hz - 400Hz; max input : AC 750V (virtual value) | ||
| Current | DC : 40mA, 400mA : ±(1.5% ± 1 digit), 10A : ±(3% ± 3 digits) AC : 40mA : ±(1.5% ± 3 digits), 400mA : ±(2% ± 1 digit), 10A : ±(5% ± 3 digits) | ||
| Impedance | 400Ω : ±(1% ± 3 digits), 40ΚΩ - 4ΜΩ : ±(1% ± 1 digit), 40MΩ : ±(1.5% ± 3 digits) | ||
| Capacitance | 51.2nF - 100uF : ±(3% ± 3 digits) | ||
